B Type Muffler

Code	Screw Thread(Size)	S(mm)
B-M5	M5	8
B-6	1/8"	12
B8	1/4"	15
B-10	3/8"	19
B-15	1/2"	22
B-20	3/4"	27
B-25	1"	36

V Type Muffler

Code	Screw Thread(Size)	S(mm)
V-M5	M5	8
V-6	1/8"	12
V-8	1/4"	15
V-10	3/8"	19
V-15	1/2"	22
V-20	3/4"	30
V-25	1"	36

TB Type Exhaust Muffling Throttle Valve

Code	Screw Thread(Size)	S(mm)
TB-6	1/8"	12
TB-8	1/4"	14
TB-10	3/8"	17
TB-15	1/2"	24
TB-20	3/4"	27
TB-25	1"	34

SC Type Muffler

Code	Screw Thread(Size)	S(mm)
SC-M5	M5	8.5
SC-6	1/8"	12
SC-8	1/4"	15
SC-10	3/8"	19
SC-15	1/2"	23
SC-20	3/4"	30
SC-25	1"	35

SEB Type Muffler

Code	Screw Thread(Size)	S(mm)
SEB-M5	M5	7
SEB-6	1/8"	12
SEB-8	1/4"	15
SEB-10	3/8"	19
SEB-15	1/2"	23
SEB-20	3/4"	30
SEB-25	1"	36

SET Type Muffler Coppler Plating Feet

Code	Screw Thread(Size)	S(mm)
SET-6	1/8"	8
SET-8	1/4"	10
SET-10	3/8"	13
SET-15	1/2"	15
SET-20	3/4"	19
SET-25	1"	24

SCQ Type Muffler

Code	Screw Thread(Size)	S(mm)
SCQ-6	1/8"	7
SCQ-8	1/4"	8
SCQ-10	3/8"	10
SCQ-15	1/2"	14
SCQ-20	3/4"	17
SCQ-25	1"	21

D Type Muffler

Code	Screw Thread(Size)	S(mm)
D-6	1/8"	8
D-8	1/4"	10
D-10	3/8"	15
D-15	1/2"	19
D-20	3/4"	20
D-25	1"	27

C Type Exhaust Muffling Throttle Valve

Code	Screw Thread(Size)	S(mm)
C-6	1/8"	13
C-8	1/4"	14
C-10	3/8"	17
C-15	1/2"	22
C-20	3/4"	27
C-25	1"	34

SDV Type Muffler

Code	Screw Thread(Size)	S(mm)
SDV-6	1/8"	13
SDV-8	1/4"	16
SDV-10	3/8"	19
SDV-15	1/2"	24
SDV-20	3/4"	30
SDV-25	1"	36

TA Type Exhaust Muffling Throttle Valve

Code	Screw Thread(Size)	S(mm)
TA-6	1/8"	14
TA-8	1/4"	16
TA-10	3/8"	17
TA-15	1/2"	24
TA-20	3/4"	27
TA-25	1"	34

SD Type Muffler

Code	Screw Thread(Size)	S(mm)
SD-6	1/8"	12
SD-8	1/4"	15
SD-10	3/8"	19
SD-15	1/2"	22
SD-20	3/4"	27
SD-25	1"	34

SEB-B-1 Plveted And Plated The Nickel Wholly

Code	Screw Thread(Size)	S(mm)
SEB-B-1-6	1/8"	12
SEB-B-1-8	1/4"	15
SEB-B-1-10	3/8"	19
SEB-B-1-15	1/2"	23
SEB-B-1-20	3/4"	30
SEB-B-1-25	1"	35

SS-V Type Stainless Steel Muffer

Code	Screw Thread(Size)	S(mm)
SS-V-M5	M5	8
SS-V-6	1/8"	12
SS-V-8	1/4"	15
SS-V-10	3/8"	19
SS-V-15	1/2"	23
SS-V-20	3/4"	30
SS-V-25	1"	36

SSDV Type Stainless Steel Muffer

Code	Screw Thread(Size)	S(mm)
SSDV-6	1/8"	13
SSDV-8	1/4"	16
SSDV-10	3/8"	19
SSDV-15	1/2"	24
SSDV-20	3/4"	30
SSDV-25	1"	36

SSM Type Muffler

Code	Screw Thread(Size)	S(mm)
SSM-M5	M5	8
SSM-6	1/8"	12
SSM-8	1/4"	15
SSM-10	3/8"	19
SSM-15	1/2"	23
SSM-20	3/4"	30
SSM-25	1"	36

SS-PDK Type Exhaust Muffling Throttle Valve

Code	Screw Thread(Size)	S(mm)
SS-PDK-6	1/8"	13
SS-PDK-8	1/4"	14
SS-PDK-10	3/8"	17
SS-PDK-15	1/2"	22
SS-PDK-20	3/4"	27
SS-PDK-25	1"	34

PTV Plastic Exhaust Muffling Throttle Valve

Code	Screw Thread(Size)	S(mm)
PTV-6	1/8"	10
PTV-8	1/4"	14
PTV-10	3/8"	17
PTV-15	1/2"	24
PTV-20	3/4"	30
PTV-25	1"	36

SB Type Muffler

Code	Screw Thread(Size)	S(mm)
SB-6	1/8"	11
SB-8	1/4"	14
SB-10	3/8"	17
SB-15	1/2"	22
SB-20	3/4"	27
SB-25	1"	33
SB-32	1-1/4"	43
SB-40	1-1/2"	51
SB-50	2"	60

LM Type Alumlnum Muffler

Code	Screw Thread(Size)	S(mm)
LM-1	1/8"	20.5
LM-2	1/4"	20.5
LM-3	3/8"	32
LM-4	1/2"	32
LM-6	3/4"	51
LM-8	1"	51

AM Type Alumlnum Muffler

Code	Screw Thread(Size)	S(mm)
AM-6	1/8"	16
AM-8	1/4"	19
AM-10	3/8"	22
AM-15	1/2"	29
AM-20	3/4"	38

PSU Type Plastic Muffler

Code	Screw Thread(Size)	S(mm)
PSU-M5	M5	7
PSU-6	1/8"	13
PSU-8	1/4"	17
PSU-10	3/8"	25
PSU-15	1/2"	25
PSU-20	3/4"
PSU-25	1"

PSE Type Plastic Muffler

Code	Screw Thread(Size)	S(mm)
PSE-M5	M5	7
PSE-6	1/8"	13
PSE-8	1/4"	17
PSE-10	3/8"	25
PSE-15	1/2"	25
PSE-20	3/4"	37
PSE-25	1"	48

SU Type Plastic Muffler

Code	Screw Thread(Size)	S(mm)
SU-6	1/8"	16
SU-8	1/4"	20
SU-10	3/8"	24
SU-15	1/2"	24
SU-20	3/4"	48
SU-25	1"	48

Silencer
